HM180 CMOS 1/2.3" 12X 4K
Full HD 4:2:2 recording at 50Mbps
The ability to record H.264 4:2:2 24-60p at 50Mbps makes this an ideal camera for broadcasting and production houses alike. The colour accuracy of 4:2:2 enables the camera to deliver exceptional colour resolution even when images are in sharp contrast to the background. This is particularly useful when strong colours are in contrast to bright backgrounds, or in green screen usage.
1/2.3-inch 12.4M CMOS sensor
This camcorder was built to deliver stunning, life-like 4K Ultra HD (3840x2160) video. JVC’s 4K CMOS sensor with 12.4M pixels delivers high sensitivity and excellent performance over a wide range of lighting conditions. Details are crisp and accurate throughout the entire image plane.
The ultra high quality imagery begins with a precision 12x F1.2–3.5 optical zoom lens (35mm equivalent: 29.6–355mm). When shooting in HD mode, Dynamic Zoom combines optical zoom and pixel mapping from a 4K image sensor to create seamless and lossless 24x zoom. This allows the camera to have a long zoom range while retaining its compact form factor.
The camcorder comes with a wide variety of connectors to meet the needs of professional applications, including HD-SDI (3G) and HDMI. Secured digital connection is assured between external devices such as a recorder or switcher. Simultaneous output from both SDI and HDMI is also possible.
The camcorder allows high-speed recording at up to 120fps (59.94Hz) / 100fps (50Hz) for smooth slow motion playback. This can be used to create artistic effects or to review action replays when examining sporting skills. The feature is only available at 1920x1080 resolution only, and offers up to 1/5 slow at 24p mode.
The detachable heavy-duty handle makes the camcorder easy to carry and also makes it simple to shoot from low angles, thanks to its built-in REC button with lock function, and zoom lever. XLR audio inputs are provided for the attachment of a professional microphone or for LINE input, complete with Phantom power supply capability.
- 4K Ultra HD recording (150 Mbps, 24/30p) to SDXC (UHS-I Speed class3) card
- 4:2:2 full HD recording at 50Mbps (24-60p)
- 3G HDSDI and HDMI output
- Single 1/2.3-inch CMOS image sensor with 12.4 million pixels (9.03 active)
- High quality integrated 12x F1.2-3.5 zoom lens (35mm equivalent: 29.5-354mm)
- Dynamic zoom in HD mode combines optical zoom and pixel mapping to create seamless and lossless 24x zoom
- Live 4K UHD output via HDMI connector
- 3.5-inch colour LCD display (920K pixel) with smart focus assist function
- 0.24-inch colour viewfinder (1.56M pixel) with smart focus assist function
- 120fps HD slow motion recording
- 2 position ND filter (1/4, 1/16)
- Wired remote control supported
- External microphone not included
- Dual SDHC/SDXC slots enable dual, backup and continuous recording
- Built-in stereo microphone
- 9 user button assignable functions
HM180 CMOS 1/2.3" 12X 4K
-
Camera options
HM180
-
Options
HM180
-
Status
New
Camera TypeHandheld Camera
HD Camera
4K Camera
-
Video Format
AVCHD 2.0(MPEG4/H.264) up to 28Mbps - 4:2:0/8bit - M2TS files
MPEG4/H.264 up to 50Mbps - 4:2:2/8bit - MOV files
MPEG4/H.264 up to 150Mbps (4K/HD) - 4:2:0/8bit - MOV files
Video ResolutionSD 480i NTSC(16:9)
SD 576i PAL(16:9)
HD 720: 1280 x 720pixels(16:9 aspect ratio)
HD 1080: 1440 x 1080pixels(4:3 aspect ratio)
HD 1080: 1920 x 1080pixels(16:9 aspect ratio)
4K UHD: 3840 x 2160pixels(16:9 aspect ratio)
Slow MotionYes
Quick Motion - Time LapseNo
Frame Rate24P/25P/30P @3840x2160Pixel
24P/25P/30P/50i/50P/60i/60P/120P @1920x1080Pixel
50i/60i @1440x1080Pixel
50i @720x576Pixel
60i @720x480Pixel
Slow motion: 120P @1920x1080PixelRec MediaSD/SD-HC/SD-XC Card
Simultaneous RECYes
Rec Time267min @28Mbps with 64GB REC-Media
148min @50Mbps with 64GB REC-Media
49min @150Mbps with 64GB REC-Media
Pre RecordYes
-
Sensor Type
CMOS
Sensor Size1/2.3"
Sensor Resolution12.4MP
Lens TypeFixed
Lens ManufacturerJVC
Focal Length29.6mm to 355mm (35mm equivalent)
Zoom12X
ApertureZoom out: F1.2 to F11
Zoom in: F3.5 to F32Control Rings2 Rings(Zoom, Focus)
Auto FocusYes
Image StabilizerYes
Filter Diameter62mm
ND FiltersYes
-
Video outputs
3G/HD/SD-SDI (BNC) 4:2:2
HDMI 4K
CVBS (Jack to RCA)
Audio inputs3-PIN XLR Mic/Line
Jack 3.5mm Stereo
Audio outputsJack 3.5mm Stereo
Jack to 2xRCA
2CH Embedded Audio SDI
2CH Embedded Audio HDMI
PC ConnectionsUSB2.0
Other ConnectionsRemote (Jack 2.5mm)
-
Min. Illumination
1LUX
StreamingNo
File TransferNo
LCD3.5"
ViewfinderYes, 0.24"
-
Extras
Dual Codec Recording.
4K output.
Logo insertion.
4:2:2 4K/HD recording.PowerJVC SSL-JVC50 Type Battery
Power adapter
No. of battery slots1
Power Consumption8W (7.4V/1.08A - 12V/0.66A)
Warranty2-Years
Country of OriginJapan
-
Total Weight (KG)
1.6
Weight in Detailweight includes battery
Total Dimensions (WxHxD) (mm)149x191x307
AvailabilityUsually in 15working days
CAMERAS-SXETIKA
OPTIONS-SXETIKA
STATUS
VIDEO SPECIFICATIONS
LENS SYSTEM
CONNECTIONS
GENERAL FEATURES
MORE SPECIFICATIONS
PHYSICAL
HM180 CMOS 1/2.3" 12X 4K
- Camera HM180E
- Battery BN-VF823
- Handle unit with Professional Audio XLR support
- AC adapter
- Instructions
